Citrix ADC MPX 5550 User Manual

Citrix ADC MPX
2. To remove the DAC, pull the tab on the top of the DAC, and then pull the DAC out of the port, as
shown in the following figure.
Figure 9. Remove a DAC from the 10G port
Bezel
The bezel of a Citrix ADC appliance is now available as a FRU and can be replaced in the field.
Note
The bezel FRU is supported only on the MPX/SDX 9100 platform.
To replace the bezel
1. Remove the five screws that attach the bezel to the chassis front.
2. Disconnect the cable (see image).
3. Discard the old bezel.
4. Reconnect the cable to the new bezel.
5. Attach the new bezel to the chassis front using screws.
Figure 1: Replacing the 2U bezel
© 1999‒2022 Citrix Systems, Inc. All rights reserved. 123
