Citrix ADC MPX 5550 User Manual

Citrix ADC MPX
The following components are visible on the back panel of the MPX 8900 appliance:
• One 240 GB or larger removable solid-state drive (SSD).
Note: Drive densities might increase as components become EOL but its size is never smaller
than the original.
• Power switch, which turns power to the appliance on or o.
– Ifthe OS is functional, press the switch for less than two seconds to powerdown the system
with a graceful shutdown.
– If the OS is not responsive, press the power switch for more than 4 seconds to force the
power o.
• One power supply, rated at 450 watts, 100–240 VAC (second power supply for redundancy is
a customer installable option). Maximum power consumption is 196 watts and typical power
consumption is 163 watts. The following table indicates the LED status of each power supply:
LED Color LED Indicates
OFF No power to any power supply in the
appliance.
Flashing RED No power to this power supply.
Flashing GREEN Power supply is in standby mode.
GREEN Power supply is functional.
RED Power supply failure.
• Disable alarm button, which is functional only when the appliance has two power supplies.
Press this button to silence the power alarm when one of two power supplies loses input power
(second power supply optional) or when a power supply is malfunctioning.
• Non-Maskable Interrupt (NMI) Button, used at the request of Technical Support to initiate a core
dump. To press this red button, which is recessed to prevent unintentional activation, use a pen,
pencil, or other pointed object. The NMI Button is also available remotely over the network in
© 1999‒2022 Citrix Systems, Inc. All rights reserved. 38
