121
INJECTION
FEATURES OF MULTIPOINT INJECTION SYSTEM
Ignition circuit
(diagr.) Component Supplier Reference Observations
1
10
11
14
15
18
Vehicle speed sensor
Engine coolant thermoswitch
Engine coolant temperature sensor
Knock sensor
Engine speed sensor
Ignition injection ECU
EATON
DAV
ELECTRIC FIL
BOSCH
ELECTRIC FIL
SIEMENS
MAGNETI
MARELLI
48P2 (HFX)
SAGEM S20000
PM1 (KFV)
BOSCH ME7 4.4
(NFU)
3-way white connector
Fixing : on the gearbox differential casing.
Fixing : on the cylinder head, alert temperature : 118 °C
Tighten to : 1.7 ± 0.1 m.daN
3-way blue connector
Fixing : on the coolant outlet housing.
Tighten to : 1.7 ± 0.3 m.daN
2-way black connector
Fixing : on the rear part of the engine block.
IMPERATIVE : Respect the tightening torque ± 0.1 m.daN
2-way black connector
Fixing : on the clutch housing.
IMPERATIVE : Respect the tightening torque 2 ± 0.1 m.daN
«Flash» type Eprom
(Reprogrammable Eprom)
