122
INJECTION
FEATURES OF MULTIPOINT INJECTION SYSTEM
Ignition circuit
(diagr.) Component Supplier Reference Observations
3
4
9
Sparking plugs
Downstream oxygen sensor
Upstream oxygen sensor
Ignition coils
SAGEM
BOSCH
CHAMPION
SAGEM
ELECTRIC FIL
Electrode gap : 0.9 mm
Tighten to : 3 m.daN
4-way blue connector
Location : on the exhaust manifold
Tighten to : 4.7 ± 0.7 m.daN
4-way green connector
Location : on the exhaust manifold
Tighten to : 4.7 ± 0.7 m.daN
4-way grey connector
