125

INJECTION

FEATURES OF SIEMENS HDI DIRECT INJECTION SYSTEM

(diagr.) Component Supplier Reference Observations

15

16

Pre-postheating unit

Preheater plugs

CARTIER

NAGARES

NGK YE04

5-way connector

Tighten to : 0.8 ± 0.1 m.daN.

Ignition circuit
