ENGINE
151
CHECKING AND SETTING THE VALVE TIMING
Engines: HFX - KFV
B1BP2MEC B1EP18NC
Setting the timing (continued).
Engines: HFX – KFV.
Slacken the screws (4) without removing them.
Remove the bottom engine support assembly
(5), and the fixing screws (4).
Slacken the nut (6).
Completely detension the belt by acting on the tensioner roller (7).
Remove the timing belt.
IMPERATIVE: Check that the tensioner roller turns freely (no tight spot).
C2 - C3 - C3 PLURIEL
