AXLES
SUSPENSION
STEERING
XSARA POWER-ASSISTED STEERING SPECIFICATIONS
Steering wheel - Power-assisted steering
- (a) : LHD = Blue.
: RHD =
White.
- (L): Shaft length = 311 ± 1.5 mm.
- (1) Steering wheel fitted with AIRBAG
(according to equipment).
-
(4) Steering column adjustment lever.
Tightening torques (m.daN).
- (2) AIRBAG to steering wheel fixing : 0.8
- (3) Steering wheel fixing : 3.3
- (5) Steering column to support fixing : 2.3
- (6) Steering cardan joint fixing : 2.3
- (b) = Locating bush.
The locating bush must be centred in the reference
window before tightening the cardan bolts
(6).
B3EP08QD
