397
AXLES
SUSPENSION
STEERING
POWER-ASSISTED STEERING SPECIFICATIONS
Power-assisted steering
XSARA
Tightening torques (m.daN).
(7) Pivot ball-joint nut :4
(8)
Link rod lock nut : 4.5
(9)
Ball-joint on steering rack : 6
(10)
Fixing on subframe :5
(11)
Hydraulic pipe connection : 2.5
(12)
Valve to housing fixing : 1.2
(13)
Plunger flange screw : 1.2
(14)
Screw fixing the steering ram
to the housing : 5.5
(15)
Nut fixing the steering ram
to the yoke : 5.5
B3EP08RD
