CITROEN C2 2004 - Checking the Oil Pressure

ENGINE
227
CHECKING THE OIL PRESSURE
To be read with the Petrol and Diesel correspondence tables
Plaque engine XFX KFV NFU 8HX
Temperature (°C) 90°C
Pressure (Bars) 3 4 1,3 3,5
Rpm 2000 4000 1000 4000
Tools (Kit 4103-T)
2279-T.Bis X X X X
4103-T.B X X X X
7001-T X X X
1503.J X
C3 - C3 Pluriel
Plaque engine HFX KFV KFU NFU 8HX 8HW 8HV 8HY
Temperature (°C) 90°C
Pressure (Bars) 3 4 1,3 3,5
Rpm 2000 4000 1000 4000
Tools (Kit 4103-T)
2279-T.Bis X X X X X X X X
4103-T.B X X X X X X X X
7001-T X X X X
1503.J XX XX
NOTE: The oil pressure
should be checked with the
engine hot, after the oil level
has been checked.
C2 - C3 - C3 PLURIEL
