CITROEN C2 2004 - Rear Axle

359
AXLES
SUSPENSION
STEERING
REAR AXLE
Tightening torques (m.daN).
(25) Rear axle fixing screw : 10 ± 1
(26) Anti-roll bar :
(27) Rear axle crossmember :
(28) Rear suspension arm silentblock yoke :
(29) Rear suspension arm silentblock :
(30) Yoke / suspension arm fixing screw : 7 ± 0,5
(31) Rear suspension arm :
(32) Stub axle bearing nut : 20 ± 2
(33) Damper :
(34) Damper upper fixing : 4,5 ± 0,4
(35) Damper lower fixing : 9,3 ± 0,9
(36) Suspension springs :
(37) Travel stop :
(38) Secondary brake cable guide support :
Private vehicles Anti-roll bar
Europe
Diameter (mm)
HFX - KFV 20,5 (tubular)
8HX 23,5 (tubular)
NFU 25 (solid)
Vehicle entreprise Diameter (mm)
8HX 20,5
(tubular)
CRD vehicles Diameter (mm)
8HX 20,5
(tubular)
NFU 25,5 (tubular)
B3DP09UP
C2
