GENERAL

BERLINGO IDENTIFICATION OF VEHICLES

E1AP0AMD

A - Chassis stamp, cold stamp

B - Manufacturer’s vehicle plate

C - Label

- RPO No.

- Paint colorr code

- Tyre pressures

D - Gearbox ident. reference - Factory serial no.

E - Engine legislation type - Factory serial no.
