352
CLUTCH
GEARBOX
TRANSMISSION
DRAINING / FILLING / TOP-UP: AL4 GEARBOX
Checking the oil level.
Prior conditions:
- Vehicle in horizontal position.
- Check gearbox is not in back-up mode.
- Remove the oil filler cap
(2).
- Add 0.5 litres extra oil into the gearbox.
- Foot on the brake, change through all the gears.
- Selection lever in position
"P".
- Engine running, at idle.
- Oil temperature:
60°C (+8°C; -2°C).
- Remove the oil level plug (3).
C3 TU3 engines Dimension «X» = 81 mm
XSARA TU5
and EW10 engines Dimension «X» = 81 mm
XSARA DW10
engines Dimension «X» = 77 mm
XSARA PICASSO EW10
engines Dimension «X» = 81 mm
Engines: KFV - NFU - RFN - RHZ
C3 - XSARA - XSARA PICASSO
B2CP3AZD
