457
BRAKES
B3FP11XD
HANDBRAKE (Adjustment)
XSARA PICASSO
Adjustment.
Remove the handbrake trim (1).
Unclip the sound-deadening (2).
Raise and support the vehicle with the rear wheels
hanging free.
Check the correct routing of the brake cables under the
vehicle.
Apply and release the handbrake 4 times.
Set the handbrake to the 5th notch.
Tighten the nut (3) until the rear brakes are applied.
Pull the handbrake lever vigorously 4 to 5 times.
Set the handbrake to the 5th notch.
Check that the rear brakes are applied.
With the handbrake released, check that the wheels
can be turned freely by hand.
Lower the vehicle.
Refit the sound-deadening (2) and the handbrake trim (1).
