506
ELECTRICAL
SYSTEM
AIR CONDITIONING SYSTEM R 134.a
Checks on the air conditioning circuit
C5HP1A8D
Key.
T/P = Average temperature (°C ) at the air vents/
high pressure
(Bars).
P = Low pressure (Bars).
TE = Exterior temperature (C°).
HP = Pressure at compressor outlet (Bars).
BP = Pressure at compressor inlet (Bars).
TA = Average temperature (°C) of air blown from
the central vents.
C3 - C3 PLURIEL BV MECANIQUE 8HX - 8HW
