87
ENGINE
SPECIAL FEATURES - TIGHTENING TORQUES (m.daN )
Engines 8HV - 8HY
Crankshaft
Bearing cap fixing screw
Tightening 3 ± 0,3
Angular tightening 140° ± 1°,4’
Crankshaft pullet hub
Tightening 3 ± 0,3
Angular tightening 180° ±5°
Cylinder block
Oil sump 1 ± 0,1
Timing belt tensioner roller 4 ± 0,4
Timing belt guide roller
2,5 ± 0,2
Timing belt guide roller support
Cylinder head
Camshaft bearing cap cover
1 ± 0,1
Inlet manifold
Exhaust manifold 2,5 ± 0,2
Cylinder head cover Screws (M6) to 1 ± 0,2
Camshaft pinion 4,3 ± 0,4
Fuel high pressure pump pinion 5 ± 0,5
C3
