CITROEN C4 PICASSO - Engine Compartment Fuses

314
In the event of a breakdown
C4-Picasso-II_en_Chap08_en-cas-panne_ed01-2016
Engine compartment fuses
Thefuseboxisplacedintheengine
compartmentnearthebattery.
Fuse N° Rating Functions
F16 20 A Headlampwash.
F18 10 A Righthandmainbeam.
F19 10 A Lefthandmainbeam.
F29 40 A Wipers.
Fuse table
Access to the fuses
F Unclipthecover,bypushingthetwored
latchestowardstherearofthevehicle.
F Changethefuse.
F When you have finished, close the cover
carefullytoensurecorrectsealingofthe
fusebox.
