CITROEN C4 PICASSO - Fitting a Wheel

299
8
In the event of a breakdown
C4-Picasso-II_en_Chap08_en-cas-panne_ed01-2016
Fitting a wheel
F Lowerthevehiclefully.
F Foldthejack3anddetachit.
List of operations
F Putthewheelinplaceonthehub.
F Screwintheboltsfullybyhand.
F Pre-tightenthesecurityboltusingthe
wheelbrace 1 fitted with the security
socket5(dependingonequipment).
F Pre-tightentheotherboltsusingthe
wheelbrace 1only.
Thejackmustonlybeusedtochangea
wheelwithadamagedtyre.
Thejackdoesnotrequireany
maintenance.
ThejackconformstoEuropean
legislation,suchasdefinedinthe
MachineryDirective2006/42/CE.
