3.2 Remote I/O
3.2.1 Basic format
The table below shows the basic format of Input data sent from the host component (such as
PLC) to a PROFIBUS unit (Absodex) and Output data sent from an Absodex to a host component.
Input data, Output data are both 8 byte data.
With 3 bytes occupation, bytes 0 to 2 will be used and others will not be available.
･ Input data ･ Output data
Byte
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
Byte
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
0 0.7 0.6 0.5 0.4 0.3 0.2 0.1 0.0 0 0.7 0.6 0.5 0.4 0.3 0.2 0.1 0.0
1 1.7 1.6 1.5 1.4 1.3 1.2 1.1 1.0 1 1.7 1.6 1.5 1.4 1.3 1.2 1.1 1.0
2 2.7 2.6 2 2.7 2.6 2.1 2.0
3 3 Response code
4 Monitor code 4
5 5
Monitor data
6 Command code 6
7 7
Loaded data
