3.6 LED Indication

The state of the module and that of the network can be displayed. See the description in

the following table for the LED indication.

LED

Color

Description of indication

Lit when the slave station is receiving normal data from the

master station.

RUN

Green

Unlit upon time-over.

Unlit during normal communication. (RUN is lit.)

ERR

Lit upon a transmission error (CRC error).

Blinks when there is an error in the station number setting or

transmission speed setting.

Red

Blinks upon time-over.

RUN

ERR
