1. Specifications
1.1 Product Configuration
Name Quantity
1 Driver unit 1
CN5 motor power connector:
PC4/3-ST-7.62 (Phoenix Contact)
1
CN4 power supply connector:
PC4/5-ST-7.62 (Phoenix Contact)
1
2 Accessories
1.2 General Specifications of Driver
Item AX9000TS/TH-U3 (PROFIBUS-DP specification)
Main
3-200V AC - 10% to 230V AC + 10% (standard)
1-100V AC - 10% to 115V AC + 10% (J1:option) (Note 1)
Power
Control
3-200V AC - 10% to 230V AC + 10% (standard)
1-100V AC - 10% to 115V AC + 10% (J1:option) (Note 1)
Frequency 50/60 Hz
Configuration Open modular type (driver, and controller)
Operating Ambient
Temperature Range
0 to 50°C
Operating Relative
Humidity Range
20 to 90%RH (No condensation allowed)
Storage Ambient
Temperature Range
-20 to 80°C
Storage Relative
Humidity Range
20 to 90%RH (No condensation allowed)
Atmosphere Free from corrosive gases, and dust
Anti-noise 1000V (P-P), pulse width 1µsec, startup 1nsec
Anti-vibration 4.9m/s
2
Mass AX9000TS: About 1.6kg, AX9000TH: About 2.1kg
Note 1) If item is “AX9000TH-U3”, “J1:option” can not be selected.
