4.5 Installationfeatures
1) Donotinstallthedryeroutdoororhighhumidityplace.
*Thisproductdoesnothavewaterproofstructure.
Waterorrainsplashing,highhumidity(=85%RHorover)couldcauseleakorfiretoelectrical
systems.
2) Operatingambienttemperatureshouldbe2to43℃ withnocondensation.
*Drainfreezeunderthetemperatureof2℃ orbelow,andthiscouldcausebreakdown.
Operationunderthetemperatureof43℃ orabovecouldstoptheoperationabnormallyorcould
shortentheservicelifeoftheproduct.
3) Installthedryerwithoutdirectsunlight,powderdust,heatingelements,corrosivegas,
explosivegas,inflammablegasorcombustibles.
*Breakdown,explosionorignitionmayresult.
4) Theinstallationfloorshouldhaveasolidconcretefoundationwithlevelandflatsurface.
*Weakorinclinfoundationmaycausenoiseandvibration.
5) Needtokeepspacesasafollowingfigureformaintenance.
Donotentertheexhaustairtoexhausttoupperpart.
*Anunusualstopmaybecarriedout.

















ＧＸ８０００series ＧＸ８１００series 

4.6Fixixation
Fixthedryerbodybyanchorboltstoavoidthedryerfallingduetoearthquakeorimpact. 

※1※2
ＧＸ８００４
ＧＸ８００６
ＧＸ８００８
ＧＸ８０１１
ＧＸ８０１５
M8×
70
φ10
ＧＸ８０２２
ＧＸ８０３７
M10×
100
φ12
ＧＸ８１５５
ＧＸ８１７５
M12×
70
φ16





