CKD Xeroaqua GX Series User Manual

＜ SM-13235-A ＞
-12-

4.7Airpiping
１） ConfirmwhichisAirinletorAiroutletbeforepiping.
２） MounttheattachedY-typestrainerbynippleorbyotherpipes.（ＧＸ８０００ Series）
【CAUTION】
IfuseiscarriedoutwithoutattachingYtypestrainerinanairinlet,itwillbecomefailure
andthecauseofgarbageclogging.
DonotmistakedirectionofYtypestrainer.
Rearside Pipesize
ＧＸ８００４ Rc
３
/
８

ＧＸ８００６ Rc
１
/
２

ＧＸ８００８ Rc
３
/
４

ＧＸ８０１１ Rc
３
/
４

ＧＸ８０１５ Rc1
ＧＸ８０２２ Rc1
ＧＸ８０３７ Rc1
１
/
２

ＧＸ８１５５ R2
ＧＸ８１７５ R2
ＧＸ８０００ series ＧＸ８１００ series

３） Installaby-passcircuitintheaircircuit.
〈Onandoffoperation〉 〈24hoursoperation〉
Installationofby-passpipingis Installationoftwodryersis
 recommended.  recommended. One is used regularly, and
 theotherisforemergency.
















Note：By-passpipingisnormallyclosed.
Watercomesoutattheendifairflowswhenitisopen.

４）Designthepipinginthewaynottoapplythepipingweighttothedryerbody.
５）Vibrationoftheaircompressorshouldnotbetransmitted.
６）Pipingmustbeabletoenduretheoperatingpressureandtemperature.Noairleakage
isallowedfromconnectionparts.
７）Usezincplatedsteelpipeorstainlesspipe.
８）Flashaircircuitbeforeconnectingpipestoremovedust,etc.
