SM-13235-A

＞

-13-



4.8DrainPiping

１）

Confirmthedrainoutletlocationbeforepiping.



Rearside



ＧＸ８０００ series ＧＸ８１００ series



Connectthedrainpipetothedrainoutlet(Rc1/4)usingencloseditems.

Haveitsendopenatmosphere.

Fit a nut and a sleeve to the transparent vinyl tube as shown in figure below. Insert a

insert-ringinthedraintubeuntilithitsthedraintube(end).Thentightenthenutbyhand.

Finally,tightenthenutoneandone-forthtoonehalfbysometoolsuchasaspanneretc.

Encloseditems: Singleelbow(φ10×R1/4)  Insert-ring(φ10)

   Draintube(O.D φ10×I.Dφ7×1.5m)



２）

Whenconnectingtheitemsonsaleasthedrainpipe,takethefollowingintoconsideration.

Theinsidediameterofdrainpipemustbeφ7orlargerandthelengthmustbe2morless.

Haveitsendopentoatmosphere.

３）

Drainmaynotbedischargedduetobackpressureifpiperisesinpartorifpipeistoolong. 

Usedown-slopepipingtoletdrainflowsmoothly.

４）

Drainisregularlydischargedcompulsorilybyair pressure.  Fixdraindischargetube,etc.

firmly.

５）

Drainmustbetreatedifoilismixedinit.  Consultindustrialwastetreatmentcompanies

fortreatment.

６）

Usethedraincookatthetimeofamaintenance.
