CKD Xeroaqua GX Series User Manual

＜ SM-13235-A ＞
-15-
ＧＸ８１００ series

・ Makeaholeforwiringontherubberbushing 
attheupperbackpartofthedryer.
・Removethefrontpanel.
Procedure

①Thefrontpanelisliftedupwards.
②Theattachmentguideisremovedfromtheright-and-leftsidepanel.
③Thefrontpanelisliftedupwardsanditextractsfromtheplugpartofthebase.









・
ConnecttheterminalblockL1,L2,L3,andtheearthleakagebreakerbywire.







３） Howtoconnectearthwire
Aspower supply codeconnection,connecttheearthwiretotheterminalboxPEand
the earth terminalin the panel.（The D sort grounding construction by the electric
constructioncontractorisrequired.）
CAUTION:Donotconnecttheearthwiretoawaterpipe,gaspipe,lightningconductor,etc.

４） Wiringcapacity(Apowercableanda groundcable )
Cablesize(mm
2
) Breakercapacity
(A)
Length10m Length20m Length30m Length50m
ＧＸ８００４ 5 2.0 2.0 2.0 2.0
ＧＸ８００６ 5 2.0 2.0 2.0 2.0
ＧＸ８００８ 5 2.0 2.0 2.0 3.5
ＧＸ８０１１ 5 2.0 2.0 3.5 5.5
ＧＸ８０１５ 5 2.0 2.0 2.0 3.5
ＧＸ８０２２ 10 2.0 2.0 3.5 5.5
ＧＸ８０３７ 10 2.0 3.5 5.5 8.0
ＧＸ８１５５ 10 2.0 5.5 8.0 14.0
ＧＸ８１７５ 15 3.5 8.0 14.0 22.0
 ･PowercableistypeVCT(600Vvinyl cabtirecable),and groundcable istype
IV
(600Vvinylinsulatedwire)asshownbytheabovechart.
