1.5” Water SpecialiSt ValVe SpecificationS
SPECIFICATIONS
WS1.5CI
WS1.5EI
WS1SQ
Service @ 1 bar/15 psi drop
Backwash @ 1.7 bar/25 psi drop
265 lpm, 15.9 m
3
/h
197 lpm, 11.8 m
3
/h
265 lpm, 15.9 m
3
/h
197 lpm, 11.8 m
3
/h
Tank Applications:
Softener
Filter (1)
12” - 30” diameter
12” - 30” diameter
12” - 30” diameter
12” - 30” diameter
Inlet/Outlet
Fitting Connections
1.5” Female BSPT or NPT 1.5” Female BSPT or NPT
Valve Material
Cycles
Regeneration
Brass
Up to 9
Downow
Brass
Up to 6
Downow
Operating Pressures
Operating Temperatures
1.4 - 8.6 bar
4° - 43° C
1.4 - 8.6 bar
4° - 43° C
Meter:
Flow Rate Range
Volume Range
Totalizer
2 - 284 lpm
0.02 - 5700 m
3
Yes
2 - 284 lpm
0.02 - 5700 m
3
Yes
Distributor Pilot
50mm O.D. or 1.90” O.D. Pipe 50mm O.D. or 1.90” O.D. Pipe
Drain Line Connection
1.25” Female NPT with
3
⁄4” Male NPT Standard
1” Male NPT Optional
1.25” Female NPT with
3
⁄4” Male NPT Standard
1” Male NPT Optional
Brine Line Connection
3
⁄4” Female NPT
1
⁄2” O.D.
Poly Tube Compression
3
⁄4” Female NPT
1
⁄2” O.D.
Poly Tube Compression
Mounting Base Options
4” - 8 UN 4” - 8 UN
Height From Top of Tank
191mm 191mm
Shipping Weight w/Meter
9.5 Kg 9.5 Kg
Electrical:
Supply Voltage
Supply Frequency
Output Voltage
Output Current
230V AC
50 Hz
12V AC
500 mA
230V AC or 6AA NMHB
50 Hz
12V AC
500 mA
1. Filter tank size calculated @ 407 lpm per m
2
of bed area/10 gpm of backwash per square foot of bed area
