Clack WS1EI User Manual

Water Specialist 1” CI Twin Alternating Specications
Options: Backwash Filter, Bypass, Weather Cover
Compatible with the following typical concentrations of regenerants or chemicals: Sodium chloride, potassium
chloride, potassium permanganate, sodium bisulte, chlorine and chloramines
1. Noryl is a trademark of Sabic Innovative Plastics IP B.V. Company
2. Filter tank size calculated @ 10 gpm of backwash per square foot of bed area/407 lpm per square meter of bed area
Inlet/Outlet Fittings ................................................................................... ¾" to 1.5” NPS
Cycles ...................................................................................................... up to 9
Valve Material ........................................................................................... Noryl (1) or equivalent
Regeneration ............................................................................................ downow/upow
FLOW RATES
Service @ 15 psi/1 bar drop (includes bypass and meter) ......... 106 lpm (6.36 m
3
/h) (28 gpm)
Backwash @ 25 psi/1.7 bar drop (includes bypass) ................... 57 lpm (3.40 m
3
/h) (15 gpm)
Cv Service .................................................................................... 7.28
Cv Backwash ............................................................................... 2.96
OPERATING PRESSURES
Minimum/Maximum ..................................................................... 20 - 125 psi (1.4 - 8.6 bar)
OPERATING TEMPERATURES
Minimum/Maximum ..................................................................... 40º - 110º F (4º – 43º C)
METER
Accuracy ...................................................................................... ± 5%
Flow Rate Range .......................................................................... 0.95 - 102 lpm
Volume Range .............................................................................. 0.02 - 5,700 m
3
Totalizer ........................................................................................ 1 m
3
- 99,999 m
3
DIMENSIONS & WEIGHT
Distributor Pilot ............................................................................ 1.050" OD Pipe (¾" NPS)
Drain Line ..................................................................................... ¾" or 1" NPT
Brine Line .....................................................................................
3
/
8
" or ½" OD Poly Tube Compression
Mounting Base ............................................................................. 2 ½"- 8 NPSM
Height From Top Of Tank ............................................................. 7
3
/
8
" (187 mm)
Weight .......................................................................................... 16 lbs (7.25 kg)
ELECTRICAL SPECIFICATIONS AC Adapter
U.S. International
Supply Voltage ............................................................................. 120V AC ............. 230V AC
Supply Frequency ........................................................................ 60 Hz .................. 50 Hz
Output Voltage ............................................................................. 12V AC ............... 12V AC
Output Current .............................................................................500 mA ............... 500 mA
TANK APPLICATIONS
Water Softener ............................................................................. 6" - 21" Diameter
Water Filter (2) .............................................................................. 6" - 21" Diameter
CYCLES OF OPERATION
Choose up to nine regeneration cycles, in any order, with a wide range of available values:
Cycle Range of values
Backwash ..................................................................................... 1 - 120 minutes
Rinse ............................................................................................. 1 - 120 minutes
Pause (service) ............................................................................. 1 - 480 minutes
Brine (co-current) ......................................................................... 1 - 180 minutes
Brine (counter-current)................................................................. 1 - 180 minutes
Rell (softener) ............................................................................. 0.05 - 95.00 Kg
Rell (lter) ................................................................................... 0.05 - 95.00 Liters
U.S. Patents: 6,402,944 • 6,444,127 • 6,776,901
