2” & 3” Water SpecialiSt ValVe SpecificationS
SPECIFICATIONS
WS2H WS3
Service @ 1 bar/15 psi drop
Backwash @ 1.7 bar/25 psi drop
473 lpm, 28.4 m
3
/h (includes meter)
473 lpm, 28.4 m
3
/h
946 lpm, 56.8 m
3
/h
833 lpm, 50.0 m
3
/h
Tank Applications:
Softener
Filter (1)
18” - 63” diameter
18” - 48” diameter
18” - 96” diameter
18” - 63” diameter
Inlet/Outlet
Fitting Connections
2” Female BSPT or NPT/
2.5” Groove Lock
3” Female BSPT or NPT
Valve Material
Cycles
Regeneration
Brass
Up to 9
Downow
Brass
Up to 9
Downow
Operating Pressures
Operating Temperatures
1.4 - 8.6 bar
4° - 43° C
1.4 - 8.6 bar
4° - 43° C
Meter:
Flow Rate Range
Volume Range
Totalizer
5.7 - 473 lpm
38 - 3796.2 liters x 1000
Yes
13 - 1,325 lpm
38 - 3796.2 liters x 1000
Yes
Distributor Pilot
63mm O.D. or 2.375” O.D. Pipe 90mm or 3.5” O.D. Pipe
3” NPS
Drain Line Connection
2” Female NPT or BSPT
2.5” Groove Lock
3” Female NPT or BSPT
Brine Line Connection
1” Male NPT elbow
3
⁄4” x 1” Solvent elbow
1” Male NPT elbow
3
⁄4” x 1” Solvent elbow
Mounting Base Options
Quick Disconnect
4” - 8 UN
6” Flange
Side Mount
Quick Disconnect
6” Flange
Side Mount
Height From Top of Tank
with 4” - 8 UN QC Base is 292mm
with 6” Flange QC Base is 294.6mm
with 6” Flange QC Base is 318mm
Shipping Weight w/Meter
22.7 Kg 25.9 Kg
Electrical:
Supply Voltage
Supply Frequency
Output Voltage
Output Current
230V AC
50 Hz
24V AC
750 mA
230V AC
50 Hz
24V AC
750 mA
1. Filter tank size calculated @ 407 lpm per m
2
of bed area/10 gpm of backwash per square foot of bed area
2. Noryl is a trademark of Sabic Innovative Plastics IP B.V. Company
