DXZ728R 29
English
STD mode/G.EQ operations
Note:
• The adjustment made in standard mode is not re-
flected in the adjustment in professional mode.
On the contrary, the adjustment made in profes-
sional mode is not reflected in the adjustment in
easy mode.
G.EQ effect ON/OFF
While the “G.EQ” indication is lit in the display,
the G.EQ effect is set to “ON”.
∗ The factory default setting is “ON”.
1. Press the [A] button and select “G.EQ”.
While “G.EQ” is selected, “G.EQ” blinks in
the display.
2. Press the [D] button. “G.EQ” in the display lit
or unlit.
∗ When “G.EQ” is unlit, the G.EQ effect is set to
OFF.
Note:
• If the G.EQ effect is set to OFF, the adjustment
made in “G.EQ operations” is not reflected in the
music source.
Selecting a G.EQ menu
1. Press the [A] button and select “G.EQ”.
2. Press the [BND] button to select “BASC” (ba-
sic). “BASC” is displayed in the function
mode indication.
3. Press one of the [DIRECT] buttons and se-
lect the desired G.EQ menu.
∗ To select the user memory, press the [BND]
button to select “USR” and press one of the
[DIRECT] buttons.
Editing/storing a G.EQ menu (User
memory)
1. Select a G.EQ menu which you want to edit
on the basis of.
2. Press and hold the [T] button for 1 second or
longer.
3. Press the [a] or [d] button to select the
frequency to be adjusted.
There are 50Hz, 100Hz, 200Hz, 400Hz,
1kHz, 3kHz and 12kHz available for the ad-
justment frequency.
∗ For details on each adjustment item, refer to
the owner’s manual supplied with the
DPH913.
4. Turn the [ROTARY] knob clockwise or
counterclockwise to make the adjustment.
The adjustment range is from –6 to 6.
5. Repeat steps 3 to 4 to complete the adjust-
ment and press the [T] button.
6. Press and hold one of the [DIRECT] buttons
for 2 seconds or longer to store the edited
contents.
∗ You can give a title to the user memory. For
the inputting method of titles, refer to the sub-
section “Entering titles” in section “Opera-
tions common to each mode”.
STD mode/DSF operations
DSF effect ON/OFF
When the “DSF” indication is lit in the display,
the DSP effect is set to “ON”.
∗ The factory default setting is “ON”.
1. Press the [A] button and select “DSF”.
2. Press the [D] button. “DSF” in the display lit
or unlit.
∗ When “DSF” is unlit, the DSF effect is set to
OFF.
Note:
• If the DSF effect is set to OFF, the adjustment
made in “DSF operations” is not reflected in the
music source.
Setting the listening position menu
1. Press the [A] button and select “DSF”.
2. Press the [a] or [d] button to set the lis-
tening position type.
There are FULL SEAT, FRONT-R, FRONT-L,
FRONT (only front seats), REAR (only rear
seats) and PASS available for the listening
position types.
∗ The factory default setting is “FULL SEAT”.
Making fine adjustment of the
listening position
1. Upon completion of setting the listening posi-
tion, press the [
] button.
2. Press the [a] or [d] button to select “BAL-
ANCE” or “FADER”. The selected item blinks.
3. Turn the [ROTARY] knob clockwise or
counterclockwise to adjust the balance and
the fader.
4. Press the [
] button to return to the DSF
mode.
DSP Operations

Clarion DXZ728R Specifications

Radio Section

FM receiving frequency range	87.5 to 108 MHz
MW receiving frequency range	531 to 1602 kHz
LW receiving frequency range	153 to 279 kHz

CD Player Section

Frequency response	5 Hz to 20 kHz
Signal to noise ratio	100 dB
Dynamic range	95 dB

General

Output power	4 x 31 W
Power supply voltage	14.4 V DC
Power consumption	Less than 15 A

Weight and Dimensions

Main unit weight	1.6 kg
Main unit dimensions	178 W x 50 H x 155 D mm
Remote control unit weight	30 g
