Clarion DXZ728R User Manual

DXZ728R 11
English
[FUNC]
[BAND]
[ ] , [ ]
[ ] , [ ]
[ ]
[MUTE]
[TA]
[DISP]
[PS/AS]
[AF]
[PTY]
Functions of Remote Control Unit Buttons
Mode
Button
Radio (RDS) CD
CD/MD changer
DVD changer
TV
Switches among radio, DAB, CD, DVD deck, CD/MD changer, DVD changer, TV, and
AUX.
Switches reception
band.
Plays the first track.
Top play.
Moves the next disc
in increasing order.
Switches reception
band.
Increases and decreases volume (in all modes).
Moves preset
channels up and
down.
No function.
Moves tracks up and down.
When pressed and held for 1 second or
longer:
Fast-forward/fast-backward.
Switches between playback and pause.
Moves preset
channels up and
down.
No function.
Turns mute on and off.
TA on and off.
Switches among main display, clock (CT) display.
Preset scan.
When pressed and
held for 2 seconds or
longer: Auto store.
AF function on and
off.
When pressed and
held for 1 second or
longer: REG function
on and off
PTY standby mode
on and off.
Scan play.
Repeat play.
Random play.
Scan play.
When pressed and
held for 1 second or
longer: Disc scan
play.
Repeat play.
When pressed and
held for 1 second or
longer: Disc repeat
play.
Random play.
When pressed and
held for 1 second or
longer: Disc random
play.
Preset scan.
When pressed and
held for 2 seconds or
longer: Auto store.
No function.
Switches between TV
and VTR.
∗ Some of the corresponding buttons on the main unit and remote control unit have different functions.

Clarion DXZ728R Specifications

Radio Section

FM receiving frequency range	87.5 to 108 MHz
MW receiving frequency range	531 to 1602 kHz
LW receiving frequency range	153 to 279 kHz

CD Player Section

Frequency response	5 Hz to 20 kHz
Signal to noise ratio	100 dB
Dynamic range	95 dB

General

Output power	4 x 31 W
Power supply voltage	14.4 V DC
Power consumption	Less than 15 A

Weight and Dimensions

Main unit weight	1.6 kg
Main unit dimensions	178 W x 50 H x 155 D mm
Remote control unit weight	30 g
