Clarion DXZ728R User Manual

DXZ728R 13
English
Setting the Beat EQ
This unit are provided with 5 types of sound tone ef-
fects stored in memory. Select the one you prefer.
∗ The factory default setting is “USER CUSTOM”.
Each time you press the [BEQ] button, the tone
effect changes in the following order:
“BASS BOOST” ➜ “IMPACT” ➜ “EXCITE” ➜
“USER CUSTOM” ➜ “TONE BYPASS” ➜
“BASS BOOST” ...
• BASS BOOST : bass emphasized
• IMPACT : bass and treble empha-
sized
• EXCITE : bass and treble empha-
sized mid de-emphasized
• USER CUSTOM : user custom
• TONE BYPASS : no sound effect
Adjusting the tone
Press the [A] button and select the item to ad-
just. Each time you press the [A] button, the
item changes in the following order:
●When “BASS BOOST” is set
“BASS BOOST” ➜ “BALANCE” ➜ “FADER”
➜ Last function mode.
●When “IMPACT” is set
“IMPACT” ➜ “BALANCE” ➜ “FADER” ➜
Last function mode.
●When “EXCITE” is set
“EXCITE” ➜ “BALANCE” ➜ “FADER” ➜
Last function mode.
●When “USER CUSTOM” is set
“BASS <GAIN>” ➜ “MID <GAIN>” ➜
“TREB<GAIN>” ➜ “BALANCE” ➜ “FADER”
➜ Last function mode.
●When “TONE BYPASS” is set
“BALANCE” ➜ “FADER” ➜ Last function
mode.
∗ Pressing the [BEQ] button for 1 second or longer
while in “USER CUSTOM” sets flat, and displays a
“BEQ FLAT” message.
Note:
• When the separately-sold digital sound processor
(DPH913) is used, the bass and treble tone ad-
justments cannot be made. To adjust the tone, re-
fer to the section “DSP Operations”.
Adjusting the bass
The bass gain, bass F (center frequency) and
bass Q can be adjusted as follows.
1. Press the [A] button and select “BASS
<GAIN>”.
2. Press the [a] or [d] button and select from
“BASS <GAIN>” ➜ “BASS <F 50>” ➜
“BASS <Q 1>” ➜ “BASS <GAIN>”.
3. Turn the [ROTARY] knob clockwise or coun-
terclockwise as needed and adjust the gain,
the F (center frequency) and the Q.
BASS GAIN : –6 to 8 (The factory default
setting is “0”)
BASS F : 50Hz/80Hz/120Hz (The
factory default setting is “50”)
BASS Q : 1/1.25/1.5/2 (The factory
default setting is “1”)
4. When the adjustment is complete, press the
[A] button several times until the function
mode is reached.
Adjusting the MID
The MID gain, MID F (center frequency) and
MID Q can be adjusted as follows.
1.
Press the [A] button and select “MID <GAIN>“.
2. Press the [a] or [d] button and select from
“MID <GAIN>” ➜ “MID <F 1k>” ➜ “MID
<Q 2>” ➜ “MID <GAIN>”.
3. Turn the [ROTARY] knob clockwise or coun-
terclockwise as needed and adjust the gain,
the F (center frequency) and the Q.
MID GAIN : –6 to 6 (The factory default
setting is “0”)
MID F : 700Hz/1KHz/2KHz (The factory
default setting is “1k”)
MID Q : 1.5/2 (The factory default
setting is “2”)
4. When the adfustment is complete, press the
[A] button several times until the function
mode is reached.
Basic Operations

Clarion DXZ728R Specifications

Radio Section

FM receiving frequency range	87.5 to 108 MHz
MW receiving frequency range	531 to 1602 kHz
LW receiving frequency range	153 to 279 kHz

CD Player Section

Frequency response	5 Hz to 20 kHz
Signal to noise ratio	100 dB
Dynamic range	95 dB

General

Output power	4 x 31 W
Power supply voltage	14.4 V DC
Power consumption	Less than 15 A

Weight and Dimensions

Main unit weight	1.6 kg
Main unit dimensions	178 W x 50 H x 155 D mm
Remote control unit weight	30 g
