EN-1286S-A
- 7 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ELECTRICAL PARTS LIST
Sub PWB(B1) section
C704 168-2222-55 2200pF K
C705 168-2222-55 2200pF K
C706 168-2222-55 2200pF K
C707 168-2222-55 2200pF K
C708 168-2222-55 2200pF K
C709 168-2222-55 2200pF K
C710 168-2222-55 2200pF K
C711 168-2222-55 2200pF K
J701 074-1159-01 OUTLET SOCKET
L601 010-3604-90 ZJYS51R5-2PB
P701 076-0324-12 PLUG(12P)
P702 076-0324-12 PLUG(12P)
PWB 039-2967-00 PWB(WITHOUT
COMPONENT)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Main PWB(B2) section
ANT101 092-2229-00 ANT-RECEPT
ANT102 092-2230-00 ANT-RECEPT
BL101 880-2026B TUNER PACK
BL251 880-1761A TMC TUNER PACK
C101 166-1801-50 18pF CH
C102 166-8097-50 8pF C CH
C103 166-3301-50 33pF CH
C104 168-4732-78 0.047uF K
C105 166-2201-50 22pF CH
C106 166-4701-50 47pF CH
C108 168-1222-55 1200pF K
C109 168-1022-55 1000pF K
C111 168-4732-78 0.047uF K
C112 168-1042-78 16V 0.1uF
C113 168-3932-78 0.039uF K
C114 168-1222-55 1200pF K
C115 168-4732-78 0.047uF K
C116 163-1073-35 16V 100uF
C117 166-4096-50 4pF CH
C118 163-1073-35 16V 100uF
C119 166-3301-50 33pF CH
C121 168-4732-78 0.047uF K
C122 166-1511-50 150pF CH
C123 168-4732-78 0.047uF K
C124 168-4732-78 0.047uF K
C125 166-1801-50 18pF CH
C126 163-1063-35 16V 10uF
C127 166-1801-50 18pF CH
C128 166-2201-50 22pF CH
C129 168-1022-55 1000pF K
C130 168-2222-55 2200pF K
C131 163-1063-35 16V 10uF
C132 166-1011-50 100pF CH
C133 168-4732-78 0.047uF K
C134 166-1011-50 100pF CH
C135 168-3322-55 3300pF K
C136 163-1063-35 16V 10uF
C137 168-1022-55 1000pF K
C138 168-1022-55 1000pF K
C139 163-1063-35 16V 10uF
C140 168-2232-55 0.022uF K
C141 168-2232-55 0.022uF K
C142 168-1022-55 1000pF K
C143 163-1073-35 16V 100uF
C144 168-2222-55 2200pF K
C145 168-4732-78 0.047uF K
C146 166-1011-50 100pF CH
C147 166-1011-50 100pF CH
C148 168-4732-78 0.047uF K
C149 168-1022-55 1000pF K
C150 168-1022-55 1000pF K
C151 163-4763-15 6.3V 47uF
C152 178-1042-78 0.1uF
C153 168-1022-55 1000pF K
C154 163-1073-35 16V 100uF
C155 166-5611-50 560pF CH
C156 168-1022-55 1000pF K
C157 168-1032-55 0.01uF K
C158 166-4701-50 47pF CH
C159 166-3311-50 330pF CH
C160 168-1042-78 16V 0.1uF
C161 178-2255-79 2.2uF
C162 166-5601-50 56pF CH
C163 166-2701-50 27pF CH
C164 119-0000-05 1/10W 0 ohm JW
C180 163-1073-35 16V 100uF
C201 168-1022-55 1000pF K
C202 168-1022-55 1000pF K
C203 168-1022-55 1000pF K
C204 168-1022-55 1000pF K
C205 166-1011-50 100pF CH
C206 168-1042-78 16V 0.1uF
C207 163-4753-65 50V 4.7uF
C209 166-1011-50 100pF CH
C210 178-2255-79 2.2uF
C211 178-2255-79 2.2uF
C214 166-1007-50 10pF CH
C215 166-1007-50 10pF CH
C216 168-1022-55 1000pF K
C217 043-0559-90 6.3V 22uF
C218 168-1022-55 1000pF K
C220 166-1011-50 100pF CH
C221 163-4753-65 50V 4.7uF
C222 168-1042-78 16V 0.1uF
C223 168-1042-78 16V 0.1uF
C224 163-4753-65 50V 4.7uF
C225 166-1511-50 150pF CH
C226 166-1511-50 150pF CH
C227 166-1011-50 100pF CH
C228 166-1011-50 100pF CH
C229 166-1011-50 100pF CH
C232 168-2232-55 0.022uF K
C233 163-2273-25 10V 220uF
C234 166-1011-50 100pF CH
C235 168-4732-78 0.047uF K
C236 042-0560-63 16V 22uF
C237 168-1222-55 1200pF K
C239 163-1063-35 16V 10uF
C240 163-4753-65 50V 4.7uF
C241 168-2232-55 0.022uF K
C242 168-1022-55 1000pF K
C243 168-1042-78 16V 0.1uF
C244 163-1073-35 16V 100uF
C245 168-1052-78 1uF
C246 168-3932-78 0.039uF K
C248 168-1022-55 1000pF K
C249 168-1032-55 0.01uF K
C250 168-3322-55 3300pF K
C251 168-3322-55 3300pF K
C252 166-5611-50 560pF CH
C253 168-3322-55 3300pF K
C254 168-2232-55 0.022uF K
C257 168-1022-55 1000pF K
C258 168-3322-55 3300pF K
C260 042-0560-63 16V 22uF
C262 168-1052-78 1uF
C267 042-0560-63 16V 22uF
C268 168-1042-78 16V 0.1uF
C269 163-3373-15 6.3V 330uF
C272 163-2273-25 10V 220uF
C275 168-1042-78 16V 0.1uF
C277 168-2222-55 2200pF K
C278 168-2222-55 2200pF K
C279 168-2222-55 2200pF K
C280 168-2222-55 2200pF K
C282 168-2232-55 0.022uF K
C283 168-2232-55 0.022uF K
C284 166-1011-50 100pF CH
C301 168-1042-78 16V 0.1uF
C302 168-1042-78 16V 0.1uF
C303 168-1042-78 16V 0.1uF
C304 168-1042-78 16V 0.1uF
C305 166-5611-50 560pF CH
C306 166-5611-50 560pF CH
C307 166-5611-50 560pF CH
C308 166-5611-50 560pF CH
C310 163-2273-25 10V 220uF
C311 168-2212-55 220pF K
C312 163-4763-35 16V 47uF
C313 166-2201-50 22pF CH
C314 166-2201-50 22pF CH
C319 166-2201-50 22pF CH
C320 166-2201-50 22pF CH
C325 166-5611-50 560pF CH
C326 166-5611-50 560pF CH
C327 166-5611-50 560pF CH
C328 166-5611-50 560pF CH
C329 166-2201-50 22pF CH
C339 168-8222-55 8200pF K
C340 168-8222-55 8200pF K
C342 168-8222-55 8200pF K
C343 168-8222-55 8200pF K
C344 168-4732-78 0.047uF K
C345 168-4732-78 0.047uF K
C346 168-4732-78 0.047uF K
C347 168-4732-78 0.047uF K
C354 168-1052-78 1uF
C360 168-4722-55 4700pF K
C401 168-1045-56 0.1uF Z
C402 168-1045-56 0.1uF Z
C403 166-2201-50 22pF CH
C404 166-2201-50 22pF CH
C406 166-1201-50 12pF CH
C407 166-1201-50 12pF CH
C408 168-1045-56 0.1uF Z
C409 168-1045-56 0.1uF Z
C410 163-4763-15 6.3V 47uF
C411 168-1045-56 0.1uF Z
C412 168-1032-55 0.01uF K
C413 168-1032-55 0.01uF K
C414 168-1042-78 16V 0.1uF
C415 166-1011-50 100pF CH
C416 168-1022-55 1000pF K
C417 168-1022-55 1000pF K
C418 168-1022-55 1000pF K
C419 168-2232-55 0.022uF K
C420 163-1073-35 16V 100uF
C422 168-2232-55 0.022uF K
C423 168-1052-78 1uF
C501 168-1042-78 16V 0.1uF
C502 042-0560-63 16V 22uF
C503 163-1073-35 16V 100uF
C504 168-1042-78 16V 0.1uF
C505 166-1511-50 150pF CH
C506 042-0579-51 16V 10uF
C507 042-0579-51 16V 10uF
