EN-1286S-A
- 10 -
WAVE FORM
POINT NAME FORM
VOLTAGE(䌖/DIV䋩
TIME(S/DIV䋩
1/5 BL101-PIN8,23 SDA B05 1
2
m 5Vpp, 50uS-10uS(Pulse 㪻㫌㫉㪸㫋㫀㫆㫅䋩
1/5 BL101-PIN9,24 SCL B05 1 2m
5Vpp, 50uS-10uS(Pulse 㪻㫌㫉㪸㫋㫀㫆㫅䋩
1/5 BL101-PIN13,28 IFOUT2 A01 50m 40n
150mVpp, 10.7MHz
䋨㪠㫋㩷㪻㪼㫇㪼㫅㪻㫊㩷㫆㫅㩷㪪㪞㩷㫀㫅㫇㫌㫋㩷㫃㪼㫍㪼㫃䋩
1/5 BL101-PIN14,29 IFOUT1 A01 50m 40n
150mVpp, 10.7MHz
䋨㪠㫋㩷㪻㪼㫇㪼㫅㪻㫊㩷㫆㫅㩷㪪㪞㩷㫀㫅㫇㫌㫋㩷㫃㪼㫍㪼㫃䋩
2/5 IC201-PIN28 SCL B05 1 5m 4Vpp, 2.5uS-10uS(Pulse 㪻㫌㫉㪸㫋㫀㫆㫅䋩
2/5 IC201-PIN29 SDA B05 1 5m 4Vpp, 4uS-10uS(Pulse 㪻㫌㫉㪸㫋㫀㫆㫅䋩
2/5 IC201-PIN38,39,43,44 AUDIO OUT A01 - - 㪘㫌㪻㫀㫆㩷㫆㫌㫋㫇㫌㫋㩷3VppMAX
2/5 IC201-PIN131 OSC IN A01 1 5n 0.13Vpp, 41.6MHz
2/5 IC201-PIN132 OSC OUT A01 1 5n 0.35vpp, 41.6MHz
2/5 IC201-PIN136,137,143,144 IF AD A01 1 25n
150mVpp, 10.7MHz
䋨㪠㫋㩷㪻㪼㫇㪼㫅㪻㫊㩷㫆㫅㩷㪪㪞㩷㫀㫅㫇㫌㫋㩷㫃㪼㫍㪼㫃䋩
4/5 IC402-PIN3 SDA B05 1 2m 5Vpp, 50uS-10uS(Pulse 㪻㫌㫉㪸㫋㫀㫆㫅䋩
4/5 IC402-PIN4 SCL B05 1 2m 5Vpp, 50uS-10uS(Pulse 㪻㫌㫉㪸㫋㫀㫆㫅䋩
4/5 IC402-PIN11 OSC OUT A01 0.5 25n 0.4vpp, 10MHz
4/5 IC402-PIN13 OSC IN A01 0.1 25n 2vpp, 10MHz
4/5 IC402-PIN17 M-CAN RX B05 0.5 5m 4vpp, 2uS-8uS(Pulse 㪻㫌㫉㪸㫋㫀㫆㫅䋩
4/5 IC402-PIN18 M-CAN TX B05 0.5 5m 5vpp, 2uS-8uS(Pulse 㪻㫌㫉㪸㫋㫀㫆㫅䋩
4/5 IC402-PIN20 NDS-HU C05 1 200u 5vpp, 100-500uS(Pulse 㪻㫌㫉㪸㫋㫀㫆㫅䋩
4/5 IC402-PIN22 HU-NDS C05 1 200u 5vpp, 200-600uS(Pulse 㪻㫌㫉㪸㫋㫀㫆㫅䋩
4/5 IC402-PIN29 SDA B05 1 5m 4.5Vpp, 4uS-10uS(Pulse 㪻㫌㫉㪸㫋㫀㫆㫅䋩
4/5 IC402-PIN30 SCL B05 1 5m 4Vpp, 2.5uS-10uS(Pulse 㪻㫌㫉㪸㫋㫀㫆㫅䋩
Sub P701-PIN5 CD-SPDIF C05 0.5 500n
1.3Vpp, 250nS-500nS(Pulse 㪻㫌㫉㪸㫋㫀㫆㫅䋩
㪁㪮㪸㫍㪼㩷㪽㫆㫉㫄㩷㪺㪿㪸㫅㪾㪼㫊
OSCILLOSCOPE
㪥㪦㪫㪜
A01
B05
C05
