Clarion EN-1286S-A User Manual

EN-1286S-A
- 9 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R202 119-1831-15 1/10W 18k ohm
R203 119-1831-15 1/10W 18k ohm
R206 119-0000-05 1/10W 0 ohm JW
R207 119-1011-15 1/10W 100 ohm
R208 119-1011-15 1/10W 100 ohm
R209 119-1011-15 1/10W 100 ohm
R210 119-1011-15 1/10W 100 ohm
R211 119-1031-15 1/10W 10k ohm
R212 119-1021-15 1/10W 1k ohm
R213 119-1021-15 1/10W 1k ohm
R214 119-5621-15 1/10W 5.6k ohm
R215 119-1011-15 1/10W 100 ohm
R216 119-5621-15 1/10W 5.6k ohm
R217 119-1011-15 1/10W 100 ohm
R218 119-1001-15 1/10W 10 ohm
R219 119-1051-15 1/10W 1M ohm
R220 119-1041-15 1/10W 100k ohm
R221 119-1041-15 1/10W 100k ohm
R222 119-5621-15 1/10W 5.6k ohm
R223 119-1011-15 1/10W 100 ohm
R224 119-1001-15 1/10W 10 ohm
R225 119-5621-15 1/10W 5.6k ohm
R226 119-1011-15 1/10W 100 ohm
R236 119-1031-15 1/10W 10k ohm
R237 119-1031-15 1/10W 10k ohm
R238 119-1011-15 1/10W 100 ohm
R239 119-1011-15 1/10W 100 ohm
R242 119-1021-15 1/10W 1k ohm
R244 119-1031-15 1/10W 10k ohm
R245 119-4731-15 1/10W 47k ohm
R247 119-4731-15 1/10W 47k ohm
R250 119-4731-15 1/10W 47k ohm
R251 119-1021-15 1/10W 1k ohm
R252 119-1021-15 1/10W 1k ohm
R253 119-1021-15 1/10W 1k ohm
R254 119-1021-15 1/10W 1k ohm
R255 119-4731-15 1/10W 47k ohm
R256 119-4731-15 1/10W 47k ohm
R257 119-1001-15 1/10W 10 ohm
R258 119-4731-15 1/10W 47k ohm
R259 119-4731-15 1/10W 47k ohm
R260 119-4731-15 1/10W 47k ohm
R261 119-4731-15 1/10W 47k ohm
R262 119-4731-15 1/10W 47k ohm
R263 119-4731-15 1/10W 47k ohm
R270 116-2401-15 1/4W 24 ohm
R290 119-3011-15 1/10W 300 ohm
R291 119-3011-15 1/10W 300 ohm
R292 119-2211-15 1/10W 220 ohm
R298 119-1031-15 1/10W 10k ohm
R299 119-1031-15 1/10W 10k ohm
R301 119-1031-15 1/10W 10k ohm
R302 119-1031-15 1/10W 10k ohm
R303 119-1031-15 1/10W 10k ohm
R304 119-1031-15 1/10W 10k ohm
R305 119-1031-15 1/10W 10k ohm
R306 119-1031-15 1/10W 10k ohm
R307 119-1031-15 1/10W 10k ohm
R308 119-1031-15 1/10W 10k ohm
R309 119-1031-15 1/10W 10k ohm
R310 119-1031-15 1/10W 10k ohm
R311 119-1031-15 1/10W 10k ohm
R312 119-1031-15 1/10W 10k ohm
R313 119-1051-15 1/10W 1M ohm
R314 119-1051-15 1/10W 1M ohm
R315 119-1051-15 1/10W 1M ohm
R316 119-1051-15 1/10W 1M ohm
R318 119-1031-15 1/10W 10k ohm
R319 119-1031-15 1/10W 10k ohm
R320 116-8211-15 1/4W 820 ohm
R321 116-8211-15 1/4W 820 ohm
R322 116-8211-15 1/4W 820 ohm
R323 119-1031-15 1/10W 10k ohm
R324 119-1031-15 1/10W 10k ohm
R325 119-1031-15 1/10W 10k ohm
R326 119-1031-15 1/10W 10k ohm
R340 119-1831-15 1/10W 18k ohm
R341 119-1831-15 1/10W 18k ohm
R342 119-1831-15 1/10W 18k ohm
R343 119-1831-15 1/10W 18k ohm
R344 119-3011-15 1/10W 300 ohm
R345 119-3011-15 1/10W 300 ohm
R346 119-5611-15 1/10W 560 ohm
R347 119-1031-15 1/10W 10k ohm
R348 119-1531-15 1/10W 15k ohm
R349 119-2721-15 1/10W 2.7k ohm
R355 116-6201-15 1/4W 62 ohm
R356 116-6201-15 1/4W 62 ohm
R360 119-1041-15 1/10W 100k ohm
R361 119-1331-15 1/10W 13k ohm
R362 119-2721-15 1/10W 2.7k ohm
R363 119-4731-15 1/10W 47k ohm
R380 119-2231-15 1/10W 22k ohm
R381 119-2721-15 1/10W 2.7k ohm
R382 119-1041-15 1/10W 100k ohm
R383 119-4731-15 1/10W 47k ohm
R401 119-1021-15 1/10W 1k ohm
R402 119-1021-15 1/10W 1k ohm
R403 119-1021-15 1/10W 1k ohm
R404 119-1021-15 1/10W 1k ohm
R405 119-1021-15 1/10W 1k ohm
R406 119-1021-15 1/10W 1k ohm
R407 119-4721-15 1/10W 4.7k ohm
R408 119-4721-15 1/10W 4.7k ohm
R409 119-4721-15 1/10W 4.7k ohm
R410 119-4721-15 1/10W 4.7k ohm
R411 119-1011-15 1/10W 100 ohm
R412 119-1011-15 1/10W 100 ohm
R413 119-1011-15 1/10W 100 ohm
R414 119-1011-15 1/10W 100 ohm
R415 119-1011-15 1/10W 100 ohm
R416 119-1011-15 1/10W 100 ohm
R417 119-0000-05 1/10W 0 ohm JW
R419 119-1031-15 1/10W 10k ohm
R422 119-1031-15 1/10W 10k ohm
R423 119-1031-15 1/10W 10k ohm
R424 119-4731-15 1/10W 47k ohm
R425 119-4731-15 1/10W 47k ohm
R426 119-5621-15 1/10W 5.6k ohm
R427 119-1231-15 1/10W 12k ohm
R432 119-1031-15 1/10W 10k ohm
R434 119-4731-15 1/10W 47k ohm
R435 119-4731-15 1/10W 47k ohm
R437 119-2231-15 1/10W 22k ohm
R438 119-1031-15 1/10W 10k ohm
R439 119-5631-15 1/10W 56k ohm
R440 119-1031-15 1/10W 10k ohm
R441 119-1031-15 1/10W 10k ohm
R442 119-5631-15 1/10W 56k ohm
R443 119-5631-15 1/10W 56k ohm
R444 119-5621-15 1/10W 5.6k ohm
R445 119-5621-15 1/10W 5.6k ohm
R446 119-1021-15 1/10W 1k ohm
R447 119-2231-15 1/10W 22k ohm
R451 119-1011-15 1/10W 100 ohm
R452 119-1011-15 1/10W 100 ohm
R453 119-0000-05 1/10W 0 ohm JW
R454 119-2231-15 1/10W 22k ohm
R455 119-2231-15 1/10W 22k ohm
R456 119-0000-05 1/10W 0 ohm JW
R457 119-0000-05 1/10W 0 ohm JW
R458 119-0000-05 1/10W 0 ohm JW
R460 119-1021-15 1/10W 1k ohm
R461 119-1021-15 1/10W 1k ohm
R501 119-1521-15 1/10W 1.5k ohm
R502 119-1031-15 1/10W 10k ohm
R504 032-0140-62 1/10W 1k ohm F
R505 032-0140-61 1/10W 3k ohm F
R506 032-0140-61 1/10W 3k ohm F
R507 116-4711-15 1/4W 470 ohm
R508 116-1521-15 1/4W 1.5k ohm
R509 116-1521-15 1/4W 1.5k ohm
R510 119-1031-15 1/10W 10k ohm
R511 119-1031-15 1/10W 10k ohm
R512 119-4721-15 1/10W 4.7k ohm
R513 119-1521-15 1/10W 1.5k ohm
R514 119-1031-15 1/10W 10k ohm
R515 119-4731-15 1/10W 47k ohm
R516 119-1541-15 1/10W 150k ohm
R517 119-1041-15 1/10W 100k ohm
R710 119-1051-15 1/10W 1M ohm
R711 119-1051-15 1/10W 1M ohm
R714 119-3321-15 1/10W 3.3k ohm
R715 119-3321-15 1/10W 3.3k ohm
R716 119-2231-15 1/10W 22k ohm
R717 119-1531-15 1/10W 15k ohm
R718 117-3301-15 1/8W 33 ohm
R719 117-3301-15 1/8W 33 ohm
R720 119-1531-15 1/10W 15k ohm
R721 119-2231-15 1/10W 22k ohm
R722 119-5631-15 1/10W 56k ohm
R723 119-5631-15 1/10W 56k ohm
R724 119-1031-15 1/10W 10k ohm
R725 119-1031-15 1/10W 10k ohm
R726 119-2231-15 1/10W 22k ohm
R727 117-3301-15 1/8W 33 ohm
R728 117-3301-15 1/8W 33 ohm
R729 119-2231-15 1/10W 22k ohm
R730 119-1051-15 1/10W 1M ohm
R731 119-1051-15 1/10W 1M ohm
R734 119-3321-15 1/10W 3.3k ohm
R735 119-3321-15 1/10W 3.3k ohm
R736 119-2231-15 1/10W 22k ohm
R737 119-1531-15 1/10W 15k ohm
R738 117-3301-15 1/8W 33 ohm
R739 117-3301-15 1/8W 33 ohm
R740 119-1531-15 1/10W 15k ohm
R741 119-2231-15 1/10W 22k ohm
R742 119-5631-15 1/10W 56k ohm
R743 119-5631-15 1/10W 56k ohm
R744 119-1031-15 1/10W 10k ohm
R745 119-1031-15 1/10W 10k ohm
R746 119-2231-15 1/10W 22k ohm
R747 117-3301-15 1/8W 33 ohm
R748 117-3301-15 1/8W 33 ohm
R749 119-2231-15 1/10W 22k ohm
SUP101 060-0122-91 DSP-141N-S00B
SUP102 060-0122-91 DSP-141N-S00B
TM101 073-0768-90 TERMINAL
TM102 073-0768-90 TERMINAL
TM401 073-0768-90 TERMINAL
TM501 073-0768-90 TERMINAL
X101 061-3013-00 4.33MHz
X201 061-3537-90 41.6MHz
X401 061-3541-90 CRYSTAL 10MHz
PWB 039-3078-00 PWB(WITHOUT
COMPONENT)
