FM tuner
Frequency Range: 87.5 MHz to 107.9 MHz
Usable Sensitivity: 11 dBf
50 dB Quieting Sensitivity: 17 dBf
Alternate Channel Selectivity: 75 dB
Stereo Separation
(
1 kHz
)
: 35 dB
Frequency Response
(
±
3 dB
)
: 30 Hz to 15 kHz
Audio
Maximum Power Output: 200 W
(
50 W X 4 ch
)
Bass Control Action
(
100 Hz
)
: ±14 dB
Treble Control Action
(
10 kHz
)
: ±14 dB
Line Output
(
with A/C 1 kHz, 10 k
Ω
)
: 1.8 V
10. SPECIFICATIONS
SD player
System: Multimedia audio system
Frequency Response: 10 Hz to 20 kHz
(
±
3 dB
)
Dynamic Range: 80 dB
(
1 kHz
)
Harmonic Distortion: 0.01%
Notes:
• Specifications comply with JEITA Standards.
• Specifications and design are subject to change
without notice for further improvement.
• Please make sure when connecting external power
amplifier, that you properly, to the car chassis,
ground the amplifier.
• If this is not done, severe damage to the source
unit may happen.
General
Power Supply Voltage:
12 V DC
(
10.8 V to 15.6 V allowable
)
, negative
ground
Current Consumption: Less than 15 A
Speaker Impedance: 4 Ω
(
4 Ω to 8 Ω allowable
)
Weight: 1.87 lb.
(
0.85 kg
)
Dimensions:
178 mm Width X 50 mm Height X 154 mm
Depth
Bluetooth
®
wireless technology
Compliance:
Bluetooth
®
1.2
Frequency Range: 2.40~2.4835 GHz, ISM band
RF Power: Class 2
(
2.5mW
)
Profiles: HFP, A2DP, AVRCP
Operating Temperature: -20ºC ~ 60ºC
Telephone Operation:
Noise reduction, echo cancellation, full duplex
telephony
Mic Input
(
External
)
: 2.2k ohm, 2V electret
