Clarion M303 Owner's Manual & Installation Manual

English
21
Red
7) Wiring and Connections
• Connecting to the external amplier
External ampliers can be connected to the 4 channel RCA output connections.
Ensure that the connectors are not grounded or shorted to prevent damage to the
unit.
8) Connecting the accessories
16-Pin Connector Extension Lead
(attached to the source unit)
Yellow wire (Memory back-up lead)
Red wire (Power lead)
Blue/White wire (Amplier turn-on lead)
Black wire (Ground lead)
Orange/White wire (Illumination lead)
Connect to remote turn-on lead of amplier
Connect to chassis ground
Connect it to the power supply terminal
for illumination
Connect directly to battery
Accessory
12V
Front Right
Black
Black
Front Right
Gray
Gray
White
White
Purple
Purple
Green
Green
Gray/Black
Gray/Black
White/Black
White/Black
Purple/Black
Purple/Black
Green/Black
Green/Black
4-Speaker system
2-Speaker system
or
Rear Right
Rear Left
Not used.
Insulate each wire
Front Left
Front Left
FUSE 15A
Antenna
(Black)
SiriusXM-Connect™ Vehicle Tuner to
be connected: Sold separately
Refer to the right
(Black)
WIRED REMOTES
Connect to external
wired Remote Control Unit
MIC
Black
Black
External
microphone
Rear audio output (Left)/
White
Black
Black
Rear audio output (Right)/
USB cable
(connect to USB memory/
iPod/iPhone device)
Subwoofer output 1
Subwoofer output 2
Gray
White
Red
Left
Right
Front audio
output terminal
White
Red
Left
Right
AUX IN
(RCB-199:Sold separately)
SUB OUT 1 REAR L
SUB OUT 2 REAR R
FRONT LFRONT RAUX L
ANT
SiriusXM
WIRED REMOTES
AUX R
