pin 77: 2ZONE_A : O : 2ZONE_A source switching terminal (AUX
= H ,DVD = L, USB = H, 2ZONE OFF =
L)
pin 78: 2ZONE_B : O : 2ZONE_B source switching terminal (AUX
= H ,DVD = H, USB = L, 2ZONE OFF =
L)
pin 79: NU : - : Not in use.
pin 80: NU : - : Not in use.
pin 81: PANEL_ON : O : LCD panel power on signal output.
pin 82: FAN_ON : O : Fan power on signal output.
pin 83 F_SEL : O : When DD-CON and RADIO, oscillation fre-
quency select.
pin 84: NU : - : Not in use.
pin 85: NU : - : Not in use.
pin 86: NU : - : Not in use.
pin 87: RDS_TEST1 : O : RDS output for the driving test.
pin 88: RDS_TEST2 : O : RDS output for the driving test.
pin 89: RDS_TEST3 : O : RDS output for the driving test.
pin 90: NU : - : Not in use.
pin 91: NU : - : Not in use.
pin 92: NU : - : Not in use.
pin 93: NU : - : Not in use.
pin 94: NU : - : Not in use.
pin 95: NU : - : Not in use.
pin 96: NU : - : Not in use.
pin 97: NU : - : Not in use.
pin 98: NU : - : Not in use.
pin 99: USA/3rd :IN: H = North America, L = 3rd area
pin100: NTSC/PAL :IN: L = NTSC, H = PAL
pin101: NOISE_TEST :IN: Radio terminal to verify the performance
test. (Usually set state = L)
pin102: BRAZ/OTHER :IN: H = Brazil, L = Other
pin103: BVSS :IN: ground.
pin104 BVDD :IN: Positive voltage supply. (+3.3V)
pin105: ILL DET :IN: Illumination detect signal input.
pin106: AV/ILL_ON : O : Select signal output to the AV_ON and
ILL_ON signal input selector.
pin107: ILL_ON : O : Illumination ON signal output.
pin108: BLK_LED : O : LED Blinking signal output.
pin109: NU : - : Not in use.
pin110: NU : - : Not in use.
pin111: NU : - : Not in use.
pin112: NU : - : Not in use.
pin113: NU : - : Not in use.
pin114: NU : - : Not in use.
pin115: SOFT_TEST1 : O : Soft test port.
pin116: SYS_ACC : O : ACC detection signal output.
pin117: NU : - : Not in use.
pin118: NU : - : Not in use.
pin119: NU : - : Not in use.
pin120: NU : - : Not in use.
pin121: DAC_RST_DVD : O : External DVD RESET output for the DAC-
IC.
pin122: TEST_MODE : O : For the test. Production output port.
pin123: OP/CL :IN: Open/close detection signal input.
pin124: TEL_IN :IN: Telephone interrupt signal input.
pin125: SD_DET2 : IN : SD Card detection. Fully inserted SD = L,
SD insert or incomplete without = H
pin126: SD_DET1 :IN: Insert SD detected, L = no SD, H = SD
in (including mid-position)
pin127: SYS_MUTE : O : System muting signal output.
pin128: SUB_MUTE : O : Sub-zone audio mute signal output.
pin129: NU : - : Not in use.
pin130: FAN_TEMP :IN: Input of the internal ADC to detect the
temperature.
pin131: NU : - : Not in use.
pin132: DVD_ON2 : O : Mechanical power 5V (Analog) ON signal
terminal.
pin133: DVD_ON3 : O : Mechanical power 8V (Servo) ON signal
terminal.
pin134: DVD_RST : O : Reset signal output for DVD mechanism.
pin135: CSN : O : Video selector to communication line out-
put.
pin136: CCLK : O : Video selector to communication line out-
put.
pin137: CDTI : O : Video selector to communication line out-
put.
pin138: VIDEO_RST : O : RESET line to the Video selector.
pin139: BACK GEAR :IN: The back gear signal input. L = back.
pin140 PKB :IN: Parking brake signal input. Auto antenna
control signal output.
pin141: AMP_REM DET :IN: Remote output short circuit detection.
pin142 AMP_REM : O : External amp control signal output.
Shorts = L
pin143: A_ANT : O : Auto antenna control signal output.
Shorts = L, Radio on = H
pin144 ACC_IN :IN : ACC detection signal intput.
052-3409-30 Toshiba TMP92FD28AFG Controller
Terminal Description
pin 1: RESET :IN: Reset signal input.
pin 2: BU DET :IN: Backup detection signal input.
pin 3: ACC DET :IN: ACC detection signal input.
pin 4: NU : - : Not in use.
pin 5: ST REQ :IN: Request signal input.
pin 6: D VDD : - : Positive voltage supply for the digital sec-
tion.
pin 7: XT 1 :IN: 3.14MHz crystal connection. (sub-clock)
pin 8: XT 2 : O : 3.14MHz crystal connection. (sub-clock)
pin 9: PW E : O : External power supply control output.
pin 10: D VSS : - : Digital ground.
pin 11: D VDD : - : Positive voltage supply for the digital sec-
tion.
pin 12: Reg V out 1 : O : regulator 1.5V output.
pin 13: VDD : - : Positive voltage supply.
pin 14: VDD : - : Positive voltage supply.
pin 15: Reg V out 2 : O : regulator 1.5V output.
pin 16: D VDD : - : Positive voltage supply for the digital sec-
tion.
pin 17: D VSS : - : Digital ground.
pin 18: P ON 3 : O : Power ON signal output.
pin 19: P ON 4 : O : Power ON signal output.
pin 20: NU : - : Not in use.
pin 21: NU : - : Not in use.
pin 22: NU : - : Not in use.
pin 23: NU : - : Not in use.
pin 24: NU : - : Not in use.
pin 25: NU : - : Not in use.
pin 26: D VSS : - : Digital ground.
pin 27: D VDD : - : Positive voltage supply for the digital sec-
tion.
pin 28: REQ O : O : Request signal output.
pin 29: NU : - : Not in use.
pin 30: NU : - : Not in use.
pin 31: NU : - : Not in use.
pin 32: NU : - : Not in use.
pin 33: P ON 2 : O : Power ON signal output.
pin 34: NU : - : Not in use.
