Clarion NX700 Service Manual

NX700/NX700E
- 6 -
Power supply cord (854-6488-50)
Connectors
1
Power supply connector
Main PWB J601
CeNET terminal for Sirius/XM
Main PWB J602
No.
1
2
3
4
5
6
7
8
9
10
11
12
Pin name
REAR L-CH (-)
REVERSE GEAR
REAR L-CH (+)
PARKING BRAKE
FRONT L-CH (-)
N.C.
FRONT L-CH (+)
ACC
FRONT R-CH (+)
AUTO ANTENNA
FRONT R-CH (-)
AMP REMOTE
No.
13
14
15
16
17
18
Pin name
REAR R-CH (+)
ILLUMINATION
REAR R-CH (-)
BUS BACK UP
BACK UP
GND
No.
1
2
3
4
5
6
7
8
9
10
11
12
Pin name
LINE OUT REAR L-CH
LINE OUT REAR R-CH
LINE OUT FRONT L-CH
LINE OUT FRONT R-CH
S-GND
S-GND
SUB-WOOFER L-CH
SUB-WOOFER R-CH
S-GND
S-GND
2-ZONE L-CH
2-ZONE R-CH
No.
13
14
15
16
17
18
19
20
21
22
23
24
Pin name
REAR VIDEO OUTPUT GND
VIDEO INPUT-1 GND
REAR VIDEO OUTPUT
VIDEO INPUT-1
AUX INPUT-1 L-CH GND
AUX INPUT-1 R-CH GND
AUX INPUT-1 L-CH
AUX INPUT-1 R-CH
VIDEO INPUT-2 GND
CCD CAMERA GND
VIDEO INPUT-2
CCD CAMERA INPUT
1
2
3
4
5
6
7
8
9
10
1113
12
17
18
14
15
16
1
2
3
4
5
6
7
8
9
10
11 13
12 14
15
16
17
18
19
20
21
22
23
24
3
RCA connector
Main PWB P203
2
No.
1
2
3
4
5
6
7
8
Pin name
GND
B/U +14V
BUS AUDIO L-CH (+)
N.C.
N.C.
BUS (+)
BUS AUDIO R-CH (+)
BUS AUDIO R-CH (-)
No.
9
10
11
12
13
Pin name
SYSTEM ACC
BUS (-)
BUS AUDIO L-CH (-)
N.C.
N.C.
Steering wheel
remote control
terminal
Main PWB J506
4
GPS antenna
jack
Navi PWB assy
5
USB terminal
Main PWB
6
5
2
1
2
1
1
2
1
2
3
4
No.
1
2
Pin name
REMOTE CONT
SHIELD GND
No.
1
2
Pin name
RF IN
GPS GND
No.
1
2
3
4
5
Pin name
VBUS
USB D (-)
USB D (+)
GND
SHIELD GND
3A
15A
Yellow
Yellow
Black
+12V main power(BACK UP)
Ground(GND)
Rear right (+)
Rear right (-)
+12V accessory(ACC)
Front right (+)
Front right (-)
Front left (+)
Front left (-)
Rear left (+)
Rear left (-)
Amplifier turn-on cord(AMP REMOTE)
Illumination
Auto antenna
Parking brake cord
Reverse gear cord
Purple
Purple/Black
Red
Gray
Gray/Black
White
White/Black
Green
Green/Black
Blue/White
Orange/White
Blue
Grass-green
Purple/white
Brown
No connection
CeNET bus backup
13
6543
10987
1211
< NX700 (QY-5014B-A) >
