Clarion NX700 Service Manual

NX700/NX700E
- 5 -
CONNECTIONS
Radio antenna jack
or
iPod/iPhone
Gray
Purple
Gray
Green
Black
Red
White
Red
White
Red
White
Yellow
Yellow
White
Red
Yellow
Right
Left
Right
Left
Right
Left
Right
Left
Rear audio
output terminal
Subwoofer output
terminal (MONO 2ch)
Video output terminal
(2-Zone audio
output terminal)
AUX audio
input terminal
Rear Vision Camera
terminal
Rear Monitor
Wireless Head phone
VTR etc.
USB terminal
Red
White
Black
GPS antenna jack
Black
Black
iPod video input terminal
Connect to the AUX audio/
video input terminal.
Red
AUX video input terminal
Front audio
output terminal
Yellow
Steering wheel
remote control
terminal
CeNET terminal
Microphone terminal of
Bluetooth phone
(Connects the supplied
microphone.)
Power supply cord
(NX700 : 854-6488-50)
(NX700E : 854-6495-50)
Connector cable
iPod with video/iPhone
Connector cable
(CCA-723/CCA-748)
Connect to the AUX audio
input terminal and the iPod video
input terminal.
RCA pin cord
(855-5576-50)
< NX700 >
(NX700)
(NX700E)
Wire connections
4-Channel Amplifier
1
4
5
6
2
3
