Clarion NX700 Service Manual

NX700/NX700E
- 29 -
1 ----------- MAIN PWB 1
2 074-2233-08 OUTLET SOCKET(MA-SENS 8P) 1
3 074-2233-50 OUTLET SOCKET(MA-PAN 50P) 1
4 074-2238-36 OUTLET SOCKET(MEC-MA 36P) 1
5 074-2233-24 OUTLET SOCKET(MA-NV 24P) 1
6 076-0478-55 PLUG(USB 5P) 1
7 076-0478-57 PLUG(7P) 1
8 092-2239-01 ANT-RECEPT 1
9 074-0881-20 OUTLET SOCKET(20P) 1
10 ----------- D/D PWB 1
11 074-1194-00 OUTLET SOCKET(13P) 1
12 074-4030-00 OUTLET SOCKET(POWER 18P) 1
13 347-7739-20 DOUBLE FACE 2
14 076-0349-02 PLUG(FAN 2P) 1
15 076-0353-20 PLUG(D/D PWB 20P) 1
16 076-0714-24 PLUG(RCA 24P) 1
17 331-4179-00 IC HOLDER(POWER) 1
18 331-4792-00 CONNECT HOLD(L) 1
19 331-4864-00 CONNECT HOLD(R) 1
20 331-4791-00 IC HOLDER(TR) 1
21 092-2216-50 ANT-RECEPT 1
22 714-2606-8B MACHINE SCREW(M2.6x6) 4
23 331-4794-00 TUNER BRKT 1
24 075-0339-00 JACK 1
25 ----------- SLIDE PWB 1
26 074-2225-58 OUTLET SOCKET(8P) 1
27 076-0478-52 PLUG(2P) 1
28 929-2170-80 DVD-MECH-MODULE 1
29 ----------- ANT PWB ASSY 1
30 855-0707-50 USB CABLE 1
31 039-3448-00 FPC(MAIN-PANEL) 1
32 ----------- NAVI PWB ASSY 1
33 816-3040-55 FLAT WIRE(MAIN-SLIDE) 1
34 039-3447-00 FPC(MAIN-MECH) 1
35 780-2604-51 SCREW(M2.6x4) 4
36 309-1911-00 FRONT PLATE 1
37 312-0503-00 SIDE CHASSIS(L) 1
38 312-0504-00 SIDE CHASSIS(R) 1
39 312-0505-01 CHASSIS 1
40 312-0506-00 UPPER CHASSIS 1
41 310-1831-02 UPPER CASE 1
42 307-0738-01 REAR PLATE 1
43 331-4806-00 PWB HOLDER(SLIDE-PWB) 1
44 331-4807-00 M-PWB HOLDER(MAIN-PWB) 1
45 313-2075-00 HEAT SINK(FAN) 1
46 347-8527-00 SHADE 1
47 347-8504-00 INSULATOR(MECH FPC) 1
48 816-3041-55 FLAT WIRE(MAIN-NAVI) 1
49 020-3053-00 DC-MOTOR(FAN) 1
50 932-0121-80 SLIDE MECH 1
51 276-0720-00 SETPLATE : NX700 1
276-0721-00 SETPLATE : NX700E 1
52 370-6444-02 ESCUTCHEON : NX700 1
370-6444-03 ESCUTCHEON : NX700E 1
53 346-0221-00 LEAHER SHEET 1
54 335-8199-00 DISC GUIDE 1
55 331-4870-00 EARTH PLATE 1
56 347-8760-00 SPACER 1
57 780-2612-50 SCREW(M2.6x12 LOCK) 2
58 335-7903-00 BUSH 2
59 313-2076-00 HEAT SINK(IC) 1
60 714-2608-8H MACHINE SCREW(M2.6x8) 3
61 714-2604-8B MACHINE SCREW(M2.6x4) 38
62 780-2604-50 IT SCREW(M2.6x4) 11
63 716-3577-00 DECORATIVE SCREW 2
64 780-2604-52 SCREW(M2.6x4) 4
65 347-8719-00 SPACER : ONLY NX700E 1
66 092-2204-03 ANT-RECEPT : ONLY NX700E 1
Note) Some parts depend on each model. The model name is specified in the description.
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
