Clarion NX700 Service Manual

NX700/NX700E
- 9 -
Panel
DISPLAY TROUBLE(BLACK DISPLAY)
CHECK ITEM CHECK POINT
1 INPUT OF INVERTER CONNECTION OF J452:MAIN PWB
J103, P701,F701(FUSE)
2 INPUT OF IC103 VIDEO:C128
NAVI:C137,C129,C130,C131
3 LEAK SHIELD CASE(INVERTER)
ARAMID
4
POWER SUPPLY VOLTAGE
IC702(INVERTER), D701
5
OUTPUT OF INVERTER(IC702)
T701
DISPLAY TROUBLE(WHITE DISPLAY)
CHECK ITEM CHECK POINT
1 INPUT SIGNAL OF PANEL
2
POWER SUPPLY VOLTAGE
IC103(CONTROLLER),IC104(FLASH)
3 OSCILLATION OF IC103 X101
4 DET ,RESET OF IC103 PIN 71 OF IC103(RESET)
5 TOUCH PANEL AROUND IC103(TP CONTROL)
6 FLASH ROM AROUND IC104(FLASH)
7 DC/DC OF IC103 Q103(1.8V),Q107(3.3V),Q100(18.5V)
8 OUTPUT LCD CONTROLLER(IC103)
DISPLAY TROUBLE(SYNCHRONIZATION)
CHECK ITEM CHECK POINT
1 INPUT SIGNAL OF PANEL
2
POWER SUPPLY VOLTAGE
IC103(LCD CONTROLLER)
3 TOUCH PANEL (REFER TO T/P SECTION)
4 INPUT OF IC103 VIDEO:PIN 29 OF J103
NAVI:C137,C129,C130,C131
5 AROUND LCD CONTROLLER(IC103)
J452:MAIN PWB
J103
J452:MAIN PWB
J103
Slide Mechanism
SLIDE-MECH TROUBLE
CHECK ITEM CHECK POINT
1 POSITION OF SD CARD SETTING OF SD CARD
2 VOLTAGE OF TP353
AND TP355
J382, NAVI PWB
5 SLIDE MECHANISM
3 MOTOR 8V IC751, IC503
4 MOTOR DRIVER IC508, J502, J5001, P5603
Navigation
NAVIGATION TROUBLE
CHECK ITEM CHECK POINT
1 POWER SUPPLY OF
NAVI PWB
J382
CONNECTION OF NAVI PWB
2 SYS-ACC(TP366)=LO Q383, IC503, J382
3 RESET(TP368)=LO Q384, IC503, J382
4 N-MONI(TP367)=LO Q385, IC503, J382
5 TX, RX LINE IC503, J382
6 NAVI PWB ASSY
DISPLAY TROUBLE(LIGHT THE BACKLIGHT)
CHECK ITEM CHECK POINT
1 CONTACT OF CONTACT OF
PANEL PWB TP AND
2 PANEL: J103
MAIN: J452
3
3.3V(TP162), VGL(TP177),
VGH(TP173), 5V(TP171)
5
OPERATION OF PORT
DISPLAY TROUBLE(NOT LIGHT THE BACKLIGHT)
CHECK ITEM CHECK POINT
1 POSITION OF
BACKLIGHT LEAD
CONTACT OF LEAD AND
SHEET METAL
2 CONNECTION OF
5 SHORT OF MOSES
3 FL+B(TP712) F701, FL+B LINE(MAIN PWB)
4 ENA(TP770)
DIMMER(TP708)
ENA/DIMMER LINE
MOSES LINE
CONNECTIONS
PANEL: J103,P701
MAIN: J452
CONNECTOR
(32, 38PIN OF IC103)
AND GND
SPIKE NOISE IN MOSES PORT
CIRCUIT LINE OF INVERTER
6
PANEL PWB AND
SHEET METAL OF
FULL AUTO MECH
SHEET METAL
CONNECTION OF
CONNECTOR
POWER SUPPLY
TO DISPLAY
4
RESISTOR OF RGB LINE
RGB OUTPUT OF
DISPLAY
5V SUPPLY TO
MOSES(130PIN OF IC103)
MOSES(126, 127PIN OF IC103)
MOS_BUF_DET(TP111): H
MOS_RST_DET(TP112): H
MOS_RESET(TP115): L
6
POWER SUPPLY(3.3V) OF
F-ROM(IC104)
POWER SUPPLY(3.3V) FILTER OF
F-ROM(IC104)
7
COMMUNICATION OF
PORT
* MOSES(IC103)
68PIN: CS; H
69PIN: SCL, 70PIN: SDA
74PIN: SPI_SDO; OPERATION
* F-ROM(IC104)
16PIN: SPI_SCK, 15PIN(SPI_SDI)
7PIN: CS; OPERATION
9PIN: W; L
8
AROUND CIRCUIT LINE OF MOSES(IC103)
PORT OF F-ROM(IC104) AND MICOM(IC503)
DISPLAY TROUBLE(WHITE DISPLAY,HORIZONTAL LINE,SCREEN BEAT)
CHECK ITEM CHECK POINT
1 RESET
2
WRITING OF F-ROM(IC104)
NORMAL WRITING OF F-ROM(IC104)
3
4
7 AROUND CIRCUIT LINE OF MOSES(IC103)
PORT OF F-ROM(IC104) AND MICOM(IC503)
SOFTWARE
CONTACT OF
ELECTRICAL PARTS OF
PANEL PWB
AND BRACKET
SHORT OF
ELECTRICAL PARTS OF
PANEL PWB
AND BRACKET
6 TCON OUTPUT OF
DISPLAY
RESISTOR OF TCON LINE
PORT OF MOSES(IC103)
POWER SUPPLY
TO DISPLAY
3.3V(TP162), VGL(TP177),
VGH(TP173), 5V(TP171)
5 RGB OUTPUT OF
DISPLAY
RESISTOR OF RGB LINE
5V SUPPLY TO
MOSES(130PIN OF IC103)
MOSES(126, 127PIN OF IC103)
