Clarion NX702E User Manual

13
English
NX702E
24-Hourformat
Touch [On] to select 24-Hour format.
Touch [Off] to select 12-Hour format.
Sound
BeatEQ
Touch the button to the right of “Beat EQ” to
show EQ setting menu. You can select : “Bass
Boost”, “Impact”, “Excite”, “Custom” or “Off”.
To adjust the value, touch [-] or [+] button on
the screen.
Touch [Back] to exit.
Balance/Fader
Touch [Set] to the right of “Balance/Fader” to
show Balance/Fader setting menu.
Touch [
] or [ ] button to adjust Fader,
and touch [
] or [ ] button to adjust
Balance.
Touch [Center] to reset the value.
Touch [Back] to exit.
Subwoofercontrol
Touch [-] or [+] button on the right of
“Subwoofer control” to adjust subwoofer
level.
Subwooferphase
Touch to select subwoofer phase Normal or
Reverse.
Highpasslter
Touch the button to the right of “High pass
lter” to show the sub-menu, then select the
lter: “Through”, “60Hz”, “90Hz” or “120Hz”.
Touch [Cancel] to exit.
Lowpasslter
Touch the button to the right of “Low pass
Filter” to show the sub-menu, then select the
lter: “Through”, “60Hz”, “90Hz” or “120Hz”.
Touch [Cancel] to exit.
TimeAligment(NormalMode)
Touch [-] or [+] button to adjust time aligment.
FrontHPF(NormalMode)
Touch [Setup] on the right to Front HPF to
spread the setting list. Touch buttons on the
screen to adjust.
RearHPF(NormalMode)
Touch [Setup] on the right to Rear HPF to
spread the setting list. Touch buttons on the
screen to adjust.
SWLPF(NormalMode)
Touch [Setup] on the right to SW LPF to
spread the setting list. Touch buttons on the
screen to adjust.
X-OverHigh(2WAY/3WayMultiMode)
Touch [Setup] on the right to X-Over High to
spread the setting list. Touch buttons on the
screen to adjust.
X-OverMid(2WAY/3WayMultiMode)
Touch [Setup] on the right to X-Over Mid to
spread the setting list. Touch buttons on the
screen to adjust.
X-Over Rear/SW (2WAY / 3Way Multi
Mode)
Touch [Setup] on the right to X-Over Rear/
SW to spread the setting list. Touch buttons
on the screen to adjust.
SpeakerGain(2WAY/3WayMultiMode)
Touch [Set] on the right to Speaker Gain.
Touch buttons on the screen to adjust.
StoreSettings
Touch [Store] on the right to Store Setting,
select Memory1, Memory2 or Memory3 to
store current settings.
RecallSettings
Touch Memory1, Memory2 or Memory3 to
recall corresponding settings.
ResetSettingMode
Touch [Reset] and [OK] buttons, the system
restart and show “Speaker Setting Mode”
menu.
Display
DimmerMode
Touch [Auto], [Day] or [Night] to choose
dimmer mode.
Auto: The dimmer is controlled by your car
light.
Dimmer
Touch [-] or [+] button to the right of “Dimmer”
to adjust dimmer.
The setting is only for Day or Night.

Clarion NX702E Specifications

General

Brand	Clarion
Model	NX702E
Category	Car Video System
Language	English
