Clarion VX400 Owner's Manual & Installation Manual

52 VX400/VZ400
English
Owner’s Manual
Radio Antenna Jack
4-Channel Amplifier
Line Out
Subwoofer
Line Out
Rear R
Line Out
Rear L
Line Out
Front R
Line Out
Video Out
Front L
Video
Audio/R
Audio/L
Video Out
Camera
Yellow
White
White
Red
Red
Red
White
Yellow
Purple
Gray
Gray
Red
Black
Black
Black
Black
White
Steering Wheel
Remote Control Terminal
Yellow
Monitor
iPod/iPhone
Connector Cable
Yellow
White
Red
Red
External
Microphone
Connection
Navigation
Connection
White
Connector Cable
Sirius
SIRIUS CONNECT VEHICLE TUNER
HD Radio™ Tuner Module
GPS Navigation
Module
Black
Antenna Cable
Connector
Cable
Antenna
VZ400
Refer to
page 53
Yellow
Black
Purple
Purple/Black
Grass-green
Gray
Gray/Black
White
White/Black
Green
Green/Black
Blue/White
Orange/White
Red
Brown
Blue
+12V main power
Ground
Rear right +
Rear right -
Parking brake cord
Purple/White
Reverse gear cord
Front right +
Front right -
Front left +
Front left -
Rear left +
Rear left -
Amplifier turn-on cord
Illumination
+12V accessory
Phone interrupt (*1)
Auto antenna
Note:
*1: Connecting the PHONE INTERRUPT terminal
The phone interrupt will mute the audio if the lead receives a negative or ground signal.

Clarion VX400 Specifications

General

Brand	Clarion
Model	VX400
Category	Car Video System
Language	English
