Clark TWLi20 - Overview

32
Overview
Overview
11
1
2
3
4
5
6
10
8
7
12
13
9
14
10
1
2
3
4
5
6
9
8
7
11
12
13
NOTE
Your lift truck may vary in appearance depending on the model and optional equipment.
Lift Truck Components
Operator Compartment
1. Steering Knob
2. Horn
3. Accessory Switches
4. Dash Display
5. Directional Control
6. Control Levers
7. Emergency Disconnect
8. Operator's Manual
9. Seatbelt
10. Accelerator
11. Brake Pedal
12. Keyswitch
13. Locking Lever
14. Hip Restraints
1. Steering Wheel
2. Upright
3. Load Backrest
4. Forks
5. Drive Wheels
6. Battery Compartment
7. Steer Tires
8. Counterweight
9. Seat
10. Overhead Guard
11. Headlights
12. Strobe Light
13. Warning Lights
