Clark TWLi20 - Twli20

90
TWLi20
TWLi20
Battery Specications
Model
Voltage Capacity Battery Weight
V Ah kg lb
TWLi20 48 360 250 551
Drive Axle Weight
Model
Drive Axle
(Loaded)
Drive Axle
(Unloaded)
kg lb kg lb
TWLi20 4916 10838 1574 3470
IMPORTANT!
The rated load capacities shown below are based on lift trucks equipped with a standard
upright (STD) with a maximum fork height (MFH) of 3000 mm (118 in), standard forks, and
a standard weight battery.
Rated Load Capacity
Model
Rated Load Capacity
Load Center: 500 mm (19.6 in) Load Center: 24 in (610 mm)
kg lb lb kg
TWLi20 2000 4409 4000 1814
Lift Truck Weight
Model
Gross Weight
(Loaded)
Empty Weight
(Unloaded)
kg lb kg lb
TWLi20 5274 11627 3460 7628
IMPORTANT!
The lift truck weights shown below are based on lift trucks equipped with a standard
upright (STD) with a maximum fork height (MFH) of 3000 mm (118 in), standard forks, and
a standard weight battery.
