Clark TWLi20 - Seat

36
Seat
Seat
1
2
3
The standard operator's seat o󰀨ers three types of adjustment for optimal operator comfort.
The seat can be adjusted for recline angle, front-to-rear position, and suspension rmness.
Adjusting the Seat Recline:
• Pull back on the side lever (1) and lean backward or forward to position the seat back
cushion. Release the lever to lock into place.
Adjusting the Seat Position:
• Pull up on the front lever (2) and slide the seat forward or backward. The seat should
be positioned so that the steering wheel and pedals are easy to reach and comfortable
to operate. Release the lever to lock into place.
Adjusting the Seat Firmness:
• Loosen or tighten the adjustment knob (3) to adjust for the weight of the operator.
WARNING
Do not adjust the seat while operating the lift truck.
