Clark TWLi20 - Armrest

38
Armrest
Armrest
1
3
2
The operator armrest o󰀨ers four-way adjustment for optimal operator comfort. The armrest
can be adjusted by recline angle, front-to-rear position, and height.
Adjusting the Armrest:
• Loosen the knob (1) to release the armrest. Adjust the armrest to the desired height.
Tighten the knob to secure the armrest.
• Loosen the bolt (2), then adjust the armrest tilt position. Tighten the bolt to secure the
armrest.
• Loosen the locking levers (3) release the armrest. Adjust the armrest to the desired
position. If needed, pull the locking lever(s) out to adjust their position.
WARNING
Do not adjust the armrest while operating the lift truck.
