22
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
SPECIFICATIONS
The details and specifications contained herein, are correct at the time of going to print.
However, CLARKE International reserve the right to change specifications at any time
without prior notice.
DUTY CYCLE
The duty cycle determines the machine ‘down time’. i.e 10% means 1 minutes operation
followed by 9 minutes of rest. The duty cycle must not be exceeded to to prevent the
thermal cutout protection from activating.
Do not exceed the stated duty cycle for this machine. Failure to heed
this warning may invalidate your warranty.
Model MIG102NG
Part No 6015600
Weight 16.65 kg
Dimensions (l x w x h) mm 420 X 192 X 362
Power Supply 230 V @ 50Hz
IP Rating IP21S
Output Min/Max Amps 35 / 90 A
Open Circuit Voltage 20-30 V DC
Rated Max Input Current 16 A
Duty Cycle (%) 10 60
Rated Welding Current (A) 90 35
Conventional Load Voltage (V) 18.5 15.7
