1 Cross Pan Head
Screw M6x40
RKTIG2600A01 32 Gun RKTIG2600A32
2 Detergent Tank RKTIG2600A02 33 Overflow Valve Cover RKTIG2600A33
3 Inner Hexagon Bolt
M8x42
RKTIG2600A03 34 Panel RKTIG2600A34
4 Rubber Foot Washer RKTIG2600A04 35 Locknut M8 RKTIG2600A35
5 Rubber Foot RKTIG2600A05 36 Flat Washer Ø5 RKTIG2600A36
6 Frame RKTIG2600A06 37 Gun Holder RKTIG2600A37
7 Locknut M8 RKTIG2600A07 38 Flat Washer Ø5 RKTIG2600A38
8 Flat Washer Ø6 RKTIG2600A08 39 Spring Washer Ø5 RKTIG2600A39
9 Locknut M6 RKTIG2600A09 40 Cross Pan Head Screw
M5x16
RKTIG2600A40
10 Inner Hexagon Bolt
M8x45
RKTIG2600A10 41 Hose RKTIG2600A41
11 Flat Washer Ø8 RKTIG2600A11 42 Hose Strap RKTIG2600A42
12 Hub Cover RKTIG2600A12 43 Handle Foam RKTIG2600A43
13 Wheel Shaft RKTIG2600A13 44 Cross Pan Head Screw
M5x42
RKTIG2600A44
14 11" Plastic Wheel RKTIG2600A14 45 Nozzle Grommet RKTIG2600A45
15 Clip RKTIG2600A15 46 Injection Hose RKTIG2600A46
16 Spring Wire RKTIG2600A16 47 Bottle Cap RKTIG2600A47
17 Baseboard RKTIG2600A17 48 Bottle RKTIG2600A48
18 Engine Cushion RKTIG2600A18 49 Bottle Frame RKTIG2600A49
19 Engine RKTIG2600A19 50 Cross Pan Head Screw
M5x40
RKTIG2600A50
20 Locknut M8 RKTIG2600A20 51 Bottle Holder RKTIG2600A51
21 Hand Wheel RKTIG2600A21 52 Locknut M8 RKTIG2600A52
22 Square Neck Bolt RKTIG2600A22 53 Detergent Tank Cap RKTIG2600A53
23 Plug RKTIG2600A23
24 Flat Key RKTIG2600A24
25 Leading Sleeve RKTIG2600A25
26 Drain Hose (320mm) RKTIG2600A26
27 Pump RKTIG2600A27
28 Flat Washer Ø8 RKTIG2600A28
29 Spring Washer Ø8 RKTIG2600A29
30 Inner Hexagon Bolt
M8x25
RKTIG2600A30
31 Lance RKTIG2600A31
