OVERVIEW
NO DESCRIPTION NO DESCRIPTION
1 Fuel Tank Cap 11 Engine On/Off Switch
2 Fuel Tank 12 Oil Filler Cap
3 Spark Plug 13 Water Outlet
4 Choke 14 Detergent Tank
5 Gun Assembly 15 Water Inlet
6 Lance 16 Bypass Drain Hose
7 Air Filter Cover 17 Hose Holder
8 Recoil Pull Start 18 Lance Holder
9 Fuel Valve 19 Priming Bottle
10 Throttle
