750-368
CBEX Elite 100-1200 HP
9-19
— Front Head Assembly
9.16 — Front Head Assembly
9.16.1 — 55” & 60”
Item Qty Description
55”
Part #
60”
Part #
1 1 Inner Door Plate Assembly 132-02731 132-02702
2 1 Bulk Plate 972-00002 972-00002
3 1 Blower Inlet Windbox 039-01740 039-01736
4 1 Front Head 132-02730 132-02704
5 9 Lug 103-00097 103-00097
6 1 Blower Pedestal Assembly 085-04050 085-03140
7 2 Front Head Support 085-01542 085-01542
8 1 Housing to Head Gasket 032-03175 032-03171
9 1 Blanket Insulation 872-01084 872-01084
10 1 Screen 930-00135 930-00135
11 150oz Coating Cement Rigidizer 872-00443 872-00443
12 1 Plate 077-02126 077-02126
13 1 Front Door Hinge 462-00183 462-00183
14 2 Gusset 059-09727 059-00805
15 1 Front Head Interior Insulation 465-02731 465-01675
To Next Page
